Channels7.1
Max256
Slots4
Ram TypeDDR5
M2 SlotsId: 69b3ab9e843b62bf624cc27c, Key: M, Size: 22110/2280, Interface: PCIe 4.0 x4, Id: 69b3ab9e843b62bf624cc27d, Key: M, Size: 22110/2280, Interface: PCIe 4.0 x4, Id: 69b3ab9e843b62bf624cc27e, Key: M, Size: 2280-22110, Interface: PCIe 4.0 x4, Id: 69b3ab9e843b62bf624cc27f, Key: M, Size: 2280-22110, Interface: PCIe 4.0 x4
Clear CmosYes
FlashbackYes
Pcie SlotsId: 69b3ab9e843b62bf624cc27a, Gen: 5.0, Lanes: 16, Quantity: 1, Id: 69b3ab9e843b62bf624cc27b, Gen: 4.0, Lanes: 4, Quantity: 2
Ecc SupportYes
Pump1
Cpu Fan1
Cpu Opt1
Case Fan3
Argb 5v2
Rgb 12v2
Usb 40
Usb 2 02
Usb 3 2 Gen 11
Usb 3 2 Gen 21
Usb 3 2 Gen 2x20
Raid SupportYes
Back Panel Ports1 x 2.5 Gb/s Ports (Realtek), 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support, 2 x USB 3.2 Gen 2 Type-A ports (red), 3 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports, 1 x HDMI 2.0 port, 1 x DisplayPort, 2 x SMA antenna connectors (2T2R), 1 x optical S/PDIF Out connector, 2 x audio jacks
U20
Sata3 Gb S0
Sata6 Gb S6
Onboard EthernetId: 69b3ab9e843b62bf624cc280, Speed: 2.5 Gb/s, Controller: Realtek
Cpu Power8-pin, 8-pin
Main Power24-pin
Wireless NetworkingWifi 6E Bluetooth 5.3
Back Connect ConnectorsNo
