Channels7.1
Max256
Slots4
Ram TypeDDR5
M2 SlotsId: 69b3ac60c0db8dfe4bc77492, Key: M, Size: 25110/22110/2580/2280, Interface: PCIe 5.0 x4, Id: 69b3ac60c0db8dfe4bc77493, Key: M, Size: 25110/22110/2580/2280, Interface: PCIe 4.0 x4, Id: 69b3ac60c0db8dfe4bc77494, Key: M, Size: 25110/22110/2580/2280, Interface: PCIe 4.0 x2
Clear CmosNo
FlashbackYes
Pcie SlotsId: 69b3ac60c0db8dfe4bc77490, Gen: 5.0, Lanes: 16, Quantity: 1, Id: 69b3ac60c0db8dfe4bc77491, Gen: 3.0, Lanes: 1, Quantity: 2
Ecc SupportNo
Cpu Fan1
Case Fan4
Rgb 12v1
Usb 40
Usb 2 02
Usb 3 2 Gen 11
Usb 3 2 Gen 20
Usb 3 2 Gen 2x21
Raid SupportYes
Back Panel Ports1 x 2.5 Gb/s Ports (Realtek), 1 x Q-Flash Plus button, 2 x SMA antenna connectors (2T2R), 1 x HDMI port, 2 x USB4 USB Type-C ports (DisplayPort), 1 x USB 3.2 Gen 2 Type-A port (Red), 3 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports, 1 x RJ-45 port, 3 x Audio jacks
U20
Sata3 Gb S0
Sata6 Gb S4
Onboard EthernetId: 69b3ac60c0db8dfe4bc77495, Speed: 2.5 Gb/s, Controller: Realtek
Cpu Power8-pin, 4-pin
Main Power24-pin
Wireless NetworkingWi-Fi 7 Bluetooth 5.4
Back Connect ConnectorsNo
